Universal terminal blocks
Distribution terminal block for mounting on DIN rails or mounting plates, e.g. for installation distributors and meter cabinets according to VDE0603.
Standards
VDE0611-1:2010-03; EN60947-7-1:2009, low-voltage switchgear and controlgear, terminal blocks for copper conductors.
Materials
Terminal body: aluminium, tinned.
Clamping screws: steel, galvanized.
Insulating housing: plastic (PA-66), impact-resistant, flame-retardant.
Continuous operating temperature: 120°C.
Electrical
Rated insulation voltage: 690VAC/DC, overvoltage category IV (Uimp=8kV), pollution degree3.
Rated insulation voltage: 1000VAC/1500VDC, overvoltage category II (Uimp=8kV), pollution degree2.
Max operating temperature: 70°C.
Mounting and protection
DIN rail TS35/... according to EN50022/EN60715 (up to UK150) or screw mounting M5.
Touch protection: IP20, finger-safe.
Safety: rounded corners.
Environment
RoHS compliant.
