Pilt on illustreeriv
|
Hargnemisklemm UK50/1PE, 1P (2ava) 2.5-50mm² 145/160A, TS35, MaxPRO, koro Kood:
1914104
Hind
|
Saadavus:
Laos
|
Kaal:
0.039 kg/tk
|
Maht:
0.0001 m3/tk
|
Hulgipakendi kogus:
10tk
|
|
|
|
Terminal Block Al/Cu 2,5-50mm², yegr
 |
|
| Name |
Terminal Block Al/Cu 2,5-50mm², yegr |
| Working temperature (ºC): |
max 80ºC |
| Housing: |
polyamide |
| Fastening: |
DIN-rail |
| Screw head: |
hexagon
|
| Screw head size: |
5 mm |
| Colour: |
yegr |
| Wire mm²: |
Cu 2,5-50 mm² Al 6-50 mm² |
| Nominal Insulation Voltage V: |
800 V |
| Nominal Rated Current A: |
Cu 160 A, Al 145 A |
| Number of poles: |
1 |
| Standard: |
EN 61238-1, EN 60947-7-1 |
| Nominal Tightening Torque Nm: |
1,5 Nm (1,5-2,5 mm2
5 Nm (4-10 mm2)
10 Nm (16-50 mm2)
|
|
|
|
File description
|
File type
|
Download link
|
|
Declaration of Conformity
|
PDF
|
Download link
|
|
|
|
|
|
