Hargnemisklemm Al/Cu UK35/1N, 1P (2holes) 2.5-35mm² 120/135A 1000VAC/ 1500VDC, Hex4 3Nm 2.5..16mm²/ 6Nm 25..35mm², TS35, sinine Kood:
1912060
Hind
Tootja
:
|
Saadavus:
Laos
|
Kaal:
0.0283 kg/tk
|
Maht:
0.0001 m3/tk
|
Hulgipakendi kogus:
10tk
|
|
|
|
| |
| Name |
Terminal Block Al/Cu 2,5-35mm2, blue |
| Working temperature (ºC): |
max 80ºC |
| Housing: |
polyamide |
| Fastening: |
DIN-rail |
| Screw head: |
hexagon
|
| Screw head size: |
4 mm |
| Colour: |
blue |
| Nominal Insulation Voltage V: |
1000 V |
| Nominal Rated Current: |
Cu 135 A, Al 120 A |
| Standard: |
EN 61238-1, EN 60947-7-2 |
|
|
|
